Swagelok SS-4-VCR-4 is a 316 stainless steel VCR face seal fitting featuring a 1/4 in. male nut. This component is engineered to provide a reliable, repeatable torque and secure sealing in metal gasket face seal systems, making it ideal for high-purity and high-vacuum industrial applications.

Specifications

Specification	Detail
Body Material	316 Stainless Steel
Cleaning Process	Standard Cleaning and Packaging (SC-10)
Connection 1 Size	1/4 in.
Connection 1 Type	Male VCR® Metal Gasket Face Seal Fitting
Flow Restrictor	No

Product Information

Male Nuts

The male nut ensures reliable performance in metal gasket face seal systems. These systems are specifically designed for environments where maintaining high purity and achieving a high-vacuum seal are critical requirements. The 316 stainless steel construction provides excellent material compatibility and durability for demanding process lines.

INFO

Standard cleaning and packaging (SC-10) ensures the fitting meets industrial requirements for cleanliness in process-sensitive applications.

Classification Codes

• eClass (10.1): 37020517
• UNSPSC (17.1001): 31161728
