Swagelok SS-400-2-2 is a 316 stainless steel 90-degree male elbow tube fitting designed to provide a reliable, leak-tight connection between 1/4 inch fractional tubing and a 1/8 inch female NPT port. This fitting is part of the Swagelok tube fitting series, known for its robust tube grip and vibration resistance, ensuring consistent performance in demanding industrial applications.

90° Elbows

This 90-degree male tube connector creates a compact, angled connection between tubing and threaded ports. It is ideal for installations in tight spaces where a straight connection is not feasible, providing a secure transition in critical fluid systems.

Technical Specifications

Specification	Detail
Body Material	316 Stainless Steel
Connection 1 Size	1/4 in.
Connection 1 Type	Swagelok® Tube Fitting
Connection 2 Size	1/8 in.
Connection 2 Type	Male NPT
Bored Through	No
Flow Restrictor	No
Cleaning Process	Standard Cleaning and Packaging (SC-10)

Industrial Classifications

Standard	Code
UNSPSC (15.1)	40183101
eClass (10.1)	37020501
UNSPSC (10.0)	40142613
eClass (6.0)	37020501

Component Interchangability

Do not mix or interchange Swagelok products or components not governed by industrial design standards—including Swagelok tube fitting end connections—with those of other manufacturers to ensure system integrity and safety.

System Design Responsibility

When selecting products, the total system design must be considered to ensure safe, trouble-free performance. Material compatibility, adequate ratings, proper installation, operation, and maintenance are the responsibilities of the system designer and user.
