Product Overview

SS-ORM2 is a Swagelok needle valve for instrumentation and process systems, with a 316 Stainless Steel body and 1/8 in. Male NPT x 1/8 in. Male NPT connections.

Core Features

• Part Number: SS-ORM2
• Body Material: 316 Stainless Steel
• Connection Configuration: 1/8 in. x Male NPT x 1/8 in. x Male NPT
• Cleaning Process: Standard Cleaning and Packaging (SC-10)

Detailed Technical Parameters

Parameter	Value
Body Material	316 Stainless Steel
Cleaning Process	Standard Cleaning and Packaging (SC-10)
Connection 1 Size	1/8 in.
Connection 1 Type	Male NPT
Connection 2 Size	1/8 in.
Connection 2 Type	Male NPT
CV Maximum	0.09
Flow Pattern	Straight (2-way)
Handle Style	Phenolic Knob
Low Emissions Certified	Yes
Maximum Temperature, °F (°C)	600 (315)
Max Temperature Pressure Rating	600°F @ 3130 PSIG /315°C @ 215 BAR
Minimum Temperature, °F (°C)	-65 (-53)
Orifice	0.080 in
Room Temperature Pressure Rating	5000 PSIG @ 100°F /344 BAR @ 37°C
Stem Tip Material	316 Stainless Steel
Stem Type	Regulating
eClass (4.1)	37010203
eClass (5.1.4)	37010201
eClass (6.0)	37010203
eClass (6.1)	37010203
eClass (10.1)	37010203
UNSPSC (4.03)	40141602
UNSPSC (10.0)	40141602
