BURKERT 20082830 is a Type 8644 valve island configured with an 11 mm 8-bank setup. It features an 8x (2x 3/2) valve function C C and is designed for DIN-rail installation. The unit operates within a nominal pressure range of 2.5 to 10 bar and supports medium temperatures from 0 °C to 50 °C. Internal bus communication is combinable with Wago systems.

Technical Attributes

Group	Attribute	Value
Function	Valve function	8x (2x 3/2) valve function C C
Valve island setup	Add-on dimension 1	11 mm
Process Connection	Pressure port	G 1/4
Process Connection	Working port	D6
Process Connection	Working connection position	Bottom (pneumatic module)
Pressure / Temperature	Nominal pressure	2.5 bar to 10 bar
Pressure / Temperature	Temperature medium	0 °C to 50 °C
Pressure / Temperature	Temperature environment	0 °C to 55 °C
Features	Integrated check valves in 3 (R) / 5 (S)	No
Features	Pneumatic HotSwap in 1 (P)	No
Properties	Type	8644
Properties	Generation	revision 2
Properties	Intermediate feed quantity	0 PCE
Properties	Mounting type	DIN-rail installation
Software / Communication	Modular version	without (due to block design)
Software / Communication	Internal bus communication	combinable with Wago
Protection Type	Protection type IP	IP20
