Swagelok B-2F-15 brass in-line particulate filter is designed to remove particulate contaminants in gas and liquid applications where space is limited. This compact inline filter allows for effective protection of downstream components while maintaining a small installation footprint within the process system.

Technical Specifications

Attribute	Detail
Body Material	Brass
Connection Size	1/8 in.
Connection Type	Swagelok® Tube Fitting (Inlet/Outlet)
Element Pore Size	15 Micron
Max Temperature	300°F (148°C)
Min Temperature	-20°F (-28°C)
Cleaning	Standard Cleaning and Packaging (SC-10)

System Performance

Swagelok inline filters are utilized in applications where space is a critical constraint. For systems requiring maintenance while still installed, tee-type filters are recommended; however, the B-2F-15 provides a streamlined solution for direct particulate removal in tight piping configurations.

Safe Product Selection

When selecting products, the total system design must be considered to ensure safe, trouble-free performance. Function, material compatibility, adequate ratings, proper installation, operation, and maintenance are the responsibilities of the system designer and user.

Installation Note

Do not mix or interchange Swagelok products or components with those of other manufacturers. This includes Swagelok tube fitting end connections, which are not governed by universal industrial design standards outside of Swagelok specifications.
